Stainless Steel Tablet Blister Packaging Machine Pharmaceutical Industry Packaging

Name: Stainless Steel Tablet Blister Packaging Machine Pharmaceutical Industry Packaging
Brand: JIANGNAN
Price: 1 USD

Brand Name : JIANGNAN

Model Number : DPP-260H

Certification : CE

Place of Origin : CHINA

MOQ : 1 UNIT

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 40UNITS /PER YEARS

Delivery Time : 45 DAYS

Packaging Details : Export-standard and sea-worthy wooden case.

Product Name : Blister Packaging Equipment

Model : DPP-260H

Material : Stainless Steel

Brand : Jiangnan

Origin : China

Warranty Period : 1 year

tPower : 380V 50HZ 10KW

Dimension : 4775X760X1620cm

Contact Now

High Speed Blister Packaging Equipment Al-Plastic (Al-Al) (DPP-260H ) Pharmaceutical Machinery

Main Technical Parameter:

Model/Item	DPP -260H
Punching Frequency	( AL/Plastic) 20-60( Times/Min)
	(AL/AL)15-30 ( Times/Min)
Max Forming Depth	Al/plastic22mmn AL/AL18mm( Made To order)
Adjustable Scope of Travel	l30-120mm(Made to order30~140mm)
Clean Compressed air	( Pressure)0.6-0.8Mpa
Air consumption( Air Compressor	0.25-0.5m³/min( Self Prepared)
Power	380V 50HZ 10KW
Dimension	4775X760X1620cm( Can Be Separate Package)
Weight	2088Kg

Applications

This machine is suitable for the blister card packing of battery, stationery, food, medical equipment, toys, hard ward, electronics, auto parts, daily use product, cosmetic etc, such as the injector, solid gum, toy car, scissor, flashlight, battery, spark plug, lip stick, hook, shaver, pencil etc.
This machine is a high-speed flat blister packaging machine with the fastest speed manufactured by us, and its running speed can reach 150 cutting/min stably (standard version). The strongest and newest full-movement computing control system is adopted by this machine; and moreover, this machine is integrates phosgene and has coaxial station, and the station of the equipment is operated flexibly and intelligently.
This machine has three main independent stations (forming, heat-sealing, batch number & pressure and cutting ) and front-tier horizontal arrangement structure consisting of two main big frame, both of which are completed by the motion computer control system respectively.

Stainless Steel Tablet Blister Packaging Machine Pharmaceutical Industry Packaging

Honor:
1.Sin-tech Spark Project of Zhejiang Province
2.The Brand-new and Quality High-tech Product of Zhejiang and National New Product
3.GMP and the certification of EU
